Electronics Training and Development Boards

The framework: the board is the cheap part

Development boards are bought on price and photographs, and then abandoned for reasons that were all predictable at the point of order. Four of them account for almost every abandoned board we have seen.

1. The toolchain outlives nothing

A board is only as usable as the software that compiles for it. The failures are mundane: an assembler or IDE that no longer installs on a current operating system; a compiler that is free only up to a code-size limit the second term's exercises exceed; a licence counted per seat when the lab has thirty seats; a vendor tool that has been replaced and whose old version is no longer downloadable.

Ask three things in writing: what toolchain is recommended, whether it is free for educational use without a code-size limit, and which operating systems the current version supports. A board whose toolchain is an open-source compiler and a standard programmer protocol will still be usable long after a board tied to one vendor's discontinued application.

2. One programmer for thirty students is no programmer

This is the most common practical failure and the easiest to prevent. If programming requires an external programmer or an in-circuit emulator pod, then the number of pods decides how many students can work at once, regardless of how many boards you bought. A class of thirty with one shared programmer becomes a demonstration with twenty-nine spectators.

• Prefer an on-board USB bootloader for teaching: every board becomes self-sufficient, a standard cable is the only accessory, and a lost cable is replaceable locally.
• But understand what a bootloader cannot do. A bootloader loads code; it does not let a student halt the processor, inspect a register or single-step. That is the difference between debugging and guessing, and it is the single biggest improvement available to a course that teaches embedded programming properly. If the syllabus expects students to find their own faults, specify in-circuit debug support and budget for enough debuggers to go round a batch, not a class.
• Ask what happens to a board whose bootloader is erased - whether it can be recovered with a standard programmer or becomes a return-to-supplier job.

3. Socketed or soldered decides the board's lifetime

Teaching boards get shorted, wired backwards and powered from the wrong supply. The question is what happens afterwards.

• A socketed through-hole microcontroller is a repair a technician does in two minutes with a spare part. A soldered surface-mount part in a fine-pitch or leadless package is, in most teaching laboratories, the end of that board.
• So ask whether the microcontroller is socketed, and ask for spare devices with the order. A handful of spare parts bought with the boards costs very little and converts the most common failure from an attrition problem into a maintenance task.
• Ask about supply protection too - reverse-polarity protection and current limiting on the board's own input. The boards that survive are the ones that forgive a wrong connection.
• And ask about the device's availability, not just the board's. A board designed around a part that is approaching obsolescence inherits that obsolescence, however current the board looks.

4. No schematic, no hardware teaching

A board supplied without a circuit diagram can only be used as a black box: students run example programs and learn the software side, and nobody can trace a fault, extend the board, or answer the question of how the LCD is actually wired. Ask explicitly for the schematic, a pin-map table, and example programs that compile as shipped. The last point matters more than it sounds - example code that needs porting before it runs absorbs the first two weeks of a module and is the reason some boards never get past the first experiment.

Choosing the architecture: match the syllabus, not the calendar

The common mistake runs in both directions, so it is worth stating plainly.

What is not a reason to choose either: which is newer, which has more memory, or which runs faster. A teaching board is never short of speed for a teaching exercise, and a bigger part teaches nothing extra about the subject on the syllabus.

What must be brought out to headers

A board that hides its signals is a demonstration unit, whatever it is called. Two specifications decide this:

• Are all port pins accessible, and at what pitch? The standard 2.54 mm pitch takes ordinary jumper wires and lets a student connect a sensor, a motor driver or a breadboard. Fine-pitch connectors or none at all mean the board can only do what it was shipped to do.
• Which peripherals are on board and which are external? A board with LEDs, switches, seven-segment displays, an LCD, a keypad and a relay gets a class to a working experiment in the first session. A bare board teaches wiring and discipline but costs time. Both are legitimate; the mistake is not deciding. For a first course, on-board peripherals; for a project or design course, headers and a breadboard beside it.

If the course needs a general-purpose wiring surface rather than a fixed board, see bread board trainers - and note the point made on that page about what that category currently holds.

What a quotation must state

• Microcontroller part number and package, and whether it is socketed.
• Programming method - on-board bootloader, external programmer, or in-circuit debugger - and how many programmers or debuggers are included per board or per batch.
• Recommended toolchain, its licence terms for educational use, any code-size limit, and the operating systems its current version supports.
• Whether the schematic and a pin-map are supplied, and whether example programs compile as shipped.
• Headers: which pins are brought out, at what pitch.
• On-board peripherals listed individually.
• Supply voltage and protection - reverse polarity, current limiting - and whether a power supply is included.
• Spares: spare microcontrollers, cables and power supplies quoted with the order.

About this listing - read before you order by code

We would rather say this than let a buyer work it out from the codes. This listing shows eight records which are five products. The series ETB-0001 to ETB-0005 is the real range - development boards, a programming board, an 8051 board, a PIC tutorial board and a PIC USB board. The records ET-0002, ET-0003 and ET-0004 are duplicates of ETB-0002, ETB-0003 and ETB-0004, distinguished only by a truncated code prefix and the numeral "2" appended to the name. Two further duplicates of the same series, ET-0001 and ET-0005, sit in our electronic training boards category - a sibling whose name differs from this one by a single letter and which contains nothing else.

Every record in the branch also carries the suffix "For Vocational Training And Didactic Labs", six words that are identical on all of them and that crowd out the part of the name a buyer actually needs. On ETB-0001 it reads "Didactic Lab" in the singular, which is how we know it was appended mechanically rather than written.

So enquire by what you need the board to do. Tell us the architecture the syllabus specifies, the class size and batch size, whether students must debug as well as program, and what they will connect to the board - we will quote the current model, name the toolchain and programmer, confirm whether the device is socketed, and tell you which code it ships under. We have recommended internally that the five duplicate ET- records be deleted, that the sibling category be merged into this one, and that the padding suffix be stripped across the branch.

Related ranges

Within training boards: electronic training boards and bread board trainers. For complete instrumented trainers rather than bare boards see microprocessor trainer kits, embedded system trainers, digital and analog trainer kits and basic electronics trainers; also embedded lab trainers and microprocessor lab trainers. The full electronics lab category lists the rest.

Frequently asked questions

What is the most common reason a development board stops being used?

The toolchain, followed closely by the programmer count. A board whose assembler or IDE no longer installs on the lab's current machines, or whose free compiler stops at a code size the later exercises exceed, becomes unusable without anything failing physically. And a class of thirty sharing one external programmer can only work one at a time. Ask what compiles the code, on which operating systems, under what licence, and how many programmers are included.

Is an on-board bootloader enough, or do we need a debugger?

A bootloader is enough to load code, and it makes every board self-sufficient with just a standard cable, which is why it suits a first course. It cannot halt the processor, inspect a register or single-step - and that is the difference between debugging and guessing. If your syllabus expects students to locate their own faults, specify in-circuit debug support and enough debuggers for a batch to work simultaneously.

Does it matter whether the microcontroller is socketed?

It decides the board's working life. Teaching boards get shorted and miswired, and a socketed through-hole device is a two-minute repair with a spare part, while a fine-pitch soldered part usually ends that board. Ask whether the device is socketed, buy a handful of spare microcontrollers with the order, and ask about reverse-polarity and current protection on the supply input.

Is the 8051 obsolete for teaching?

Not for what it is used to teach. Its register model and instruction set are small enough for a student to hold in mind and examine on paper, which is exactly what an architecture or assembly-language module needs, and many syllabi specify it. It is the wrong choice for teaching modern embedded C and peripherals - but a modern 32-bit part is equally the wrong choice for cycle-counting assembly. Match the board to the module, and buy both if the programme covers both.

Why insist on the schematic?

Because without it the board can only be used as a black box. Nobody can trace a fault, extend the board, or answer how the LCD or keypad is actually wired - so the hardware half of the subject goes untaught and a single failure takes the board out of service permanently. Ask for the schematic, a pin-map table, and example programs that compile as shipped rather than needing porting first.

Why does this listing show eight records for five products?

Because three of them are duplicates: ET-0002, ET-0003 and ET-0004 repeat ETB-0002, ETB-0003 and ETB-0004 under a truncated code prefix with "2" added to the name, and two more duplicates of the same series sit in the near-identically named sibling category. We have set this out here rather than leave you to deduce it, and have recommended the duplicates be deleted and the categories merged. Enquire by architecture and class size and we will quote the real model.

Key takeaways

• The board is the cheap part. Toolchain, programmer count, device availability and the schematic decide whether it is still in use in five years.
• Count the programmers, not the boards. One shared programmer caps how many students can work at once, whatever the board quantity.
• A bootloader loads code; a debugger teaches debugging. Specify in-circuit debug if students must find their own faults.
• Socketed devices and spare parts turn the commonest failure from attrition into maintenance.
• Match architecture to module: a small classic core for assembly and architecture, a modern part for embedded C and peripherals. Speed and memory are not the criteria.
• No schematic, no hardware teaching. Insist on it, with a pin-map and example code that compiles as shipped.
