Structural Mechanics Lab

Structural Mechanics Lab Lab Equipment Manufacturer, Supplier and Exporter in India

Ray Export is a leading manufacturer and supplier of Structural Mechanics Lab in India,

Quick answer. Judge each rig on whether it measures the quantity the experiment is about, not on its name. A three hinged arch is only worth running if the horizontal thrust is measured rather than inferred and the load can travel along the span in known increments; a beam rig needs a stiff, bolted frame, supports that genuinely rotate and slide, and dial gauges on independent mounts. Buy the Clerk Maxwell reciprocal theorem apparatus and run it first, because a reciprocity failure exposes the friction, flex or play that corrupts every other result. And order by full product name, because this listing has code faults.

The structural mechanics apparatus in this listing

These are the records to ask for by name: an apparatus for verification of Clerk Maxwell's reciprocal theorem; a behaviour of columns and struts apparatus; a curved member apparatus; an elastically coupled beam apparatus; an elastic properties of a deflected beam apparatus; a three hinged arch apparatus; and, further into the listing, a suspension bridge, trusses, a bifilar and trifilar suspension apparatus and a statics and vibrations set. Together they cover what a structural mechanics course examines: deflection and strain energy in beams and curved members, the thrust and influence lines of an arch, the stability of columns, and the dynamics of simple suspended systems.

And the honest part, which we would rather you heard from us. This listing also holds a substantial number of records that are not structural mechanics at all. They were copied in when the catalogue was imported, and most carry a digit on the end of the name. Among them, on the first page alone, are a mechanical heat pump trainer, a refrigeration trainer, an air conditioning trainer and an ice plant trainer - all of which belong with refrigeration and air conditioning. Deeper in there are a roll crusher, a trommel and a vibrating screen, which belong with mechanical operations; steam engine models and a wind tunnel, which belong with machines; and an automatic transmission, an injection petrol engine and several mechanism rigs, which belong with theory of machines and the automotive ranges.

Three code faults in this listing, which matter if you order by code. One code appears twice against two different products - an elastically coupled beam apparatus and an elastic properties of a deflected beam apparatus share a number. One code is written without zero padding, so a code search will not find it. And there are gaps in the sequence. Quote the full product name, not the code, and ask us to confirm the item and its specification on the proforma invoice. We are correcting the data.

Reciprocity as the Calibration

Here is an idea worth building a structures laboratory around, and the apparatus for it is the first item in this listing.

Clerk Maxwell's reciprocal theorem says something that sounds too neat to be true: the deflection at point A caused by a load at point B is exactly equal to the deflection at B caused by the same load at A. It is a consequence of linear elastic behaviour, and it holds for any elastic structure.

Which makes it the most useful check a structures laboratory has. If reciprocity does not hold on your apparatus, the theory is not wrong - your apparatus is. Friction at a support, a bearing that does not rotate freely, a frame that is not level, a dial gauge mount that moves, play in a pin joint: every one of those breaks reciprocity, and every one of them is also quietly corrupting the beam deflection and arch thrust results on the bench next to it. So run the reciprocal theorem experiment first, on a new apparatus and after any move, and treat it as the laboratory's calibration rather than as one experiment among many.

If reciprocity fails, look atWhat it also corrupts
Friction or stiction at the supportsEvery beam deflection result, in the direction of under-reading
A frame that is not level, or that flexesAll deflection measurements - the apparatus deflects with the specimen
Play in pin jointsTruss member forces and arch thrust, unpredictably
A dial gauge mounted on the loaded member or on a flexing bracketEverything that gauge reads

The three hinged arch, and the measurement that makes it work

The three hinged arch is statically determinate, which is exactly why it is taught: the horizontal thrust can be found from statics alone and then checked against measurement. The experiment is only worth running if the horizontal thrust is actually measured rather than inferred - so ask how the thrust is read, what its range and resolution are, and whether the support that takes it is genuinely free to move in the direction it must.

Ask also whether the load can be moved along the span in known increments, because the real lesson is the influence line - how the thrust varies with load position - and that needs a series of positions rather than one. A rig with a fixed load point demonstrates a number; a rig with a travelling load teaches a method.

Beams, curved members and the coupled beam

These three rigs teach strain energy and the methods built on it, and they share the same practical requirements as beam work everywhere: a stiff frame that is bolted down, supports that rotate and slide as the idealisation assumes, dial gauges on independent mounts, and beams whose dimensions have been measured rather than taken as nominal, because the second moment of area is calculated from them and a nominal section carries an error straight into the answer.

For the curved member apparatus, ask the radius and section and whether both in-plane and out-of-plane loading can be applied; for the coupled beam, ask how the coupling stiffness is set and whether it can be varied, since the interesting result is what happens as the coupling changes. The columns and struts apparatus is the stability experiment, and it carries the warning that belongs with every buckling rig: buckling is sudden, and a strut released at its critical load can leave the apparatus, so ask for a guard, an end retention arrangement and a stated maximum load. The same subject, with more apparatus, is in our strength of materials lab listing.

What to ask for on the quotation

For each rig: the experiment and the quantities measured, with resolution against the magnitudes expected; frame stiffness, mass and bolt-down requirement; support type and whether rotation and sliding are genuinely free; thrust or reaction measurement where the experiment needs it; whether loads can be moved in known increments; specimens or members supplied, with measured dimensions and material, and the price of further sets; dial gauges and indicators, with independent mounting; guarding on buckling and anything that fails suddenly; the worksheets supplied; bench or floor mounting and footprint; consumables and spares with prices; and the warranty, commissioning and local service position. For any certification stated here, contact us for the latest copies of the relevant certificates before you tender on it.

Related ranges: strength of materials lab for beams, torsion, springs, strain gauges, fatigue and creep, machines for the demountable structures sets, trusses, arches and girders, universal testing machines for the load frames and verification certificates, and models for theory of machines for dynamics. The full set is listed under mechanical lab equipments. For a quotation, send us your syllabus experiment list - on this listing in particular it lets us quote the structural apparatus and leave out the records that should not be in this category.

Frequently asked questions

Why run the reciprocal theorem experiment first?

Because it is the most useful check a structures laboratory has. Clerk Maxwell's reciprocal theorem says the deflection at A caused by a load at B equals the deflection at B caused by the same load at A; it follows from linear elastic behaviour and holds for any elastic structure. If it does not hold on your apparatus, the apparatus is at fault: friction at a support, a bearing that does not rotate freely, a frame that is not level, a moving dial gauge mount or play in a pin joint. Each of those also corrupts the neighbouring beam and arch results, so treat this experiment as the laboratory's calibration.

What should I check on a three hinged arch apparatus?

The three hinged arch is statically determinate, so the horizontal thrust can be found from statics and then checked against measurement - which is only worth doing if the thrust is actually measured rather than inferred. Ask how the thrust is read, its range and resolution, and whether the support that takes it is genuinely free to move in the direction it must. Ask also whether the load can be moved along the span in known increments, because the real lesson is the influence line. A rig with a fixed load point demonstrates a number; a rig with a travelling load teaches a method.

What makes a beam or curved member rig give reliable results?

A stiff frame that is bolted down, supports that rotate and slide as the idealisation assumes, dial gauges on independent mounts, and beams whose dimensions have been measured rather than taken as nominal, because the second moment of area is calculated from them and a nominal section carries its error straight into the answer. For the curved member apparatus, ask the radius and section and whether both in-plane and out-of-plane loading can be applied. For the elastically coupled beam, ask how the coupling stiffness is set and whether it can be varied, since that change is the interesting result.

Is the columns and struts buckling apparatus safe for students?

Only with the right protection. The columns and struts apparatus is the stability experiment, and buckling is sudden: a strut released at its critical load can leave the apparatus. Ask for a guard, an end retention arrangement and a stated maximum load before ordering, and make sure students stand clear when approaching the critical load. If your course needs more buckling and stability work than one rig provides, the same subject is covered with more apparatus in the strength of materials lab listing, so compare the two before deciding which to quote.

Why does this listing include refrigeration trainers, crushers and engines?

Because records were copied in when the catalogue was imported, and most carry a digit on the end of the name. The heat pump, refrigeration, air conditioning and ice plant trainers belong with refrigeration and air conditioning; the roll crusher, trommel and vibrating screen with mechanical operations; the steam engine models and wind tunnel with machines; and the automatic transmission, injection petrol engine and mechanism rigs with theory of machines and the automotive ranges. Send your syllabus experiment list, so the quotation covers the structural apparatus and leaves out the records that do not belong here.

How should I order, given the code faults in this listing?

Quote the full product name rather than the code. One code appears twice against two different products, the elastically coupled beam apparatus and the elastic properties of a deflected beam apparatus; one code is written without zero padding, so a code search will not find it; and there are gaps in the sequence. For each rig, ask for the experiment and quantities measured with their resolution, the frame stiffness and bolt-down requirement, the specimens supplied with measured dimensions and material, the worksheets, the footprint, spares, warranty, commissioning and local service, all confirmed in writing on the quotation.

Key takeaways

  • Reciprocity is the laboratory's calibration: run the Clerk Maxwell experiment first, on a new rig and after any move.
  • Measured, not inferred: the three hinged arch is only worth buying if the horizontal thrust is actually read.
  • A travelling load teaches a method: ask whether loads move along the span in known increments for influence lines.
  • Measured beam dimensions, not nominal: the second moment of area carries any dimensional error straight into the answer.
  • Guard every buckling rig: ask for a guard, end retention and a stated maximum load on the columns and struts apparatus.
  • Order by product name: codes here are duplicated, unpadded or missing, and many records are not structural apparatus.

About this page

Ray Export is a manufacturer and exporter of laboratory, scientific and educational equipment based at Plot No. 449, HSIIDC Industrial Area, Saha, Ambala, Haryana 133104, India. Enquiries: [email protected], +91-9817319615.

Written by Palak Mall, Senior Content Writer. Technically reviewed by Arvind Kumar, Lab Equipment Specialist, 12+ years in laboratory and testing instrumentation. Last updated: 17 October 2026.

Every specification, including the quantities measured, their resolution and the frame and support details, is confirmed in writing on the quotation. For certificates, contact us for the latest copies of the relevant certificates. No price is quoted here. Listing defects noticed: this listing holds many records that are not structural mechanics - heat pump, refrigeration, air conditioning and ice plant trainers, a roll crusher, trommel and vibrating screen, steam engine models, a wind tunnel, an automatic transmission, an injection petrol engine and mechanism rigs - most with a digit appended to the name; one code is shared by the elastically coupled beam and the elastic properties of a deflected beam apparatus; one code lacks zero padding; and the code sequence has gaps.

Study Of A Pre Tensioned Bolt

SML-0068

Investigation Of A Pre Tensioned Bolt Analysis can be made of the burdens and strains created in a rush after various techniques for fixing, and permits displaying of the conduct of a catapulted association when pivotally stacked. Showing goals The mechanical assembly permits the accompanying analyses: Deformations in a rush in the wake of fixing with a spanner or with a torque. Impact of jolt pre-tensioning utilizing a pressure driven stacking framework. Impact of shifting the stacking position. Impact of changing the materials on the stacking torque. Static examination of sliding with grinding on a helical screw contact surface or plane. Basic stacking and weights on a plane area. Mohrs Circles of pressure, vital burdens and their headings. Specialized details The pre-stacked jolt gathering is made out of : A 16mm rush on which are settled three sets of oppositely contradicted 45° strain. These allow the estimation of augmentation and pressure in the jolt. A tubular segment with 2 strain checks mounted at 180° to gauge the pressure in the get together at various statures. A stacking tube to apply jolt pre-stack or to apply stacking power at different positions along the shot get together. A physically worked pressure driven pump. A micrometer dial check to quantify expansions over the total get together. Nuts and washers of different materials. Hardware Package : Pre-stacked jolt get together with pressure driven stacking framework and manual pump. An arrangement of washers. Specialized manual and educating notes. Measurements and weight 15 diam. x 37 cm – 12 kg Pump: 40 x 10 x 14 mm – 3,5kg Essential prerequisites Electrical supply : 220V, 50 Hz Additional required hardware : Extensometer connect. A ring spanner 24 mm. A torque of limit 40 – 200 Nm with 24 mm nut.

Strain Bridge

SML-0069

Strain Bridge The high-differentiate advanced show gives an immediate perusing in miniaturized scale strains, for half or full scaffold task of the six channels. Estimations with a quarter connect design can be made by including a resistor. The measure factor can be balanced in the vicinity of 1 and 5. Each channel can be adjusted independently by methods for multiturn potentiometers. A simple yield for each channel allows the show of the signs utilizing an oscilloscope or a plotter, and furthermore information obtaining. With the extension energisation of 2.5 V, strain measures of 120 W least can be utilized. These can be in Constantan, Isoelastic Karma or Platinum – Tungsten combinations. The 20 000 point computerized show permits estimations in the range 20 000 mm/m, whatever the measure composite. Specialized determinations Number of channels: 6. Working reach: 20 000 m/m. Determination: 1 m/m. Extension energisation: 2.5 V – Stability: 10-4. Measure setup: Full or half extension with checks of 120 to 5000 WQuarter connect with extra resistor. Information impedance: 1010 W. Parity: utilizing multi-turn potentiometers 2000 W/W. Measure factor read specifically in plain view flexible from 1 to 5 by multi-turn locking potentimeters.resolution: 0.001. Speaker: exactness 1 %. linearity: 0.002 %drift: 0.25V/°C clamor: under 13V for every Hzcommon mode rejection:< 100 dB. Simple yields: independant yield for the 6 channels, utilizing Cannon 9 stick connectors max. yield voltage: 10 V band pass: 0 – 10 kHz. 2 V for 20000 W/W. Insignificant load: 22000 W. Check associations: 15 stick Cannon connectors way fast connector. Alternative : Data procurement and preparing with an IBM-PC or perfect miniaturized scale PC, the framework can arrange and read the six channels at the same time. It contains three components: Software bundle Allows for every arrangement of estimations : Test distinguishing proof. Strain connect initialisation. Channel determination, pick up, arrangement (full or half-connect), check factor, diagram design, inspecting rate, add up to number of acquisitions. Perception. Protect. Print-out. Sparing test to document. Card-connect interfacing link. Simple/Digital obtaining card. Highlights : Reads 16 single simple information sources or 8 differential simple data sources. 12 bit advanced change, or a determination of 4096 focuses full scale. Acknowledges most extreme voltages of 0 to 10 volts in unipolar mode and 5 volts in bi-polar mode. Settled recurrence procurement, through implicit time Dimensions and weight 265 x 105 x 84 mm. Net weight : 1.8 Kg. Fundamental prerequisites Voltage : 220 V, 50 or 60 Hz.

Stressmaster Polariscope

SML-0070

Stressmaster Polariscope Primarily intended for instructive use, based on an instrument for every understudy in an examination gathering, the polariscope can likewise be utilized to advantage in industry for the improvement of new item outlines. Showing destinations The Stressmaster polariscope can be used for the customized learning of photoelastic standards. Specialized particulars The offices offered with the Stressmaster polariscope cover the investigation of both isoclinics and isochromatics, and additionally the estimation of fragmentary periphery arranges by the Senarmont or Tardy strategies. A wide assortment of model shapes can be examined utilizing the table-top polariscope. Photoelastic models, delivered in Photoflex material, might be stacked in strain, pressure or bowing to suit systematic necessities. The stacked models can be seen in white light or, then again, in an estimated monochromatic light by essentially swinging a green channel into the polarizing field. Display stacking on the Stressmaster polariscope is made by methods for a deadweight framework, using different connections for elastic, compressive and bowing burdens, as appeared. Optical Field : 152mm distance across. A wooden cover is given to fenced in area of the polariscope when the unit isn't being used. Standard model shapes incorporate shafts, strain individuals, circles and snares. A standard arrangement of six photoelastic models is provided, together with well ordered directions and trial comes about. Measurements and weight Width : 305mm; Length: 380mm; Height: 310mm Unit Weight : 9Kg.

Universal Strut Apparatus

SML-0071

All inclusive Strut Apparatus Reversible solidified load pieces are given with the goal that the swaggers can be tried under the accompanying conditions: 1. The two finishes stuck. 2. The two finishes settled. 3. One end stuck, one end settled. Specialized particulars The mechanical assembly has been intended to oblige swaggers of appropriate lengths inside the range 400/800 mm. The swaggers are rectangular in area, subsequently guaranteeing that the redirection happens in a foreordained plane. The heap is connected to the swagger by methods for a spring balance and a stacking bar. The bar rotates on a nut which can be balanced vertically with the goal that the bar can be kept up in the even position amid stacking, along these lines guaranteeing that a genuine pivotal load can be provided all through the test. A light horizontal load is connected to the swagger to guarantee the heading of redirection, the extent of which would then be able to be estimated by methods for a dial pointer. One arrangement of swaggers for each end condition is provided with the mechanical assembly. One arrangement of masses. Analysis manual Optional supplies : An arrangement of load pieces, shrubberies and examples are accessible to enable trials to be directed on round examples. Measurements and weight 880 x 580 x 1240 mm approx. Net Weight : 56 kg.

Elutriator

SML-0072

Comprehensive Strut Apparatus Reversible hardened load pieces are given with the objective that the swaggers can be attempted under the going with conditions: 1. The two completions stuck. 2. The two completions settled. 3. One end stuck, one end settled. Specific particulars The mechanical get together has been expected to oblige swaggers of fitting lengths inside the range 400/800 mm. The swaggers are rectangular in region, accordingly ensuring that the redirection occurs in a predestined plane. The pile is associated with the swagger by strategies for a spring balance and a stacking bar. The bar turns on a nut which can be adjusted vertically with the objective that the bar can be kept up in the even position in the midst of stacking, thusly ensuring that a bona fide urgent load can be given all through the test. A light even load is associated with the swagger to ensure the heading of redirection, the degree of which would then have the capacity to be evaluated by techniques for a dial pointer. One course of action of swaggers for each end condition is furnished with the mechanical get together. One course of action of masses. Examination manual Optional supplies : A course of action of load pieces, greenery and illustrations are available to empower trials to be coordinated on round cases. Estimations and weight 880 x 580 x 1240 mm approx. Net Weight : 56 kg.

Rotary Vacuum Filter1

SML-0073

Revolving Vacuum Filter The most widely recognized kinds of ceaseless vacuum channel is the rotating drum channel. A flat drum with an opened face turns at under 2 RPM in an unsettled slurry trough. A channel medium, for example, canvas, covers the substance of drum, which is incompletely submerged in the fluid. Under the opened tube shaped face of the primary drum is a moment, littler drum with a strong surface. Between the two drums are spiral segments isolating the annular space into discrete compartments, each associated by an inward pipe to one opening in the pivoting plate of the turning valve Vacuum and air are on the other hand connected to every compartment as the drum turns. The set-up comprises of stainless steel drum moving in gunmetal sections and is partitioned in 6 compartments, secured by a Stainless Steel work. A canvas channel is utilized for filtration. The entire get together is fitted with a SS trough in which an instigator is given. To make the unit an independent a slurry blending and nourish game plan, recipient tanks, vacuum pump, control board are given. Experimentation: To examine the execution of a Rotary Vacuum Filter. To consider the activity of Rotary Vacuum Filter under vacuum. To decide the particular cake obstruction and medium opposition. Utilities Required : Electric Supply: Single stage, 220 V AC, 3.5 kW. Water supply. Deplete. Slurry required to performing test. Specialized Details : Filter Drum : Material Stainless Steel, Dia. 250 mm, Length 350 mm. Work : Material Stainless Steel Filter : Canvas Cloth No. of Zones : 6 Nos. Drive for Drum : FHP engine coupled to a Reduction Gear Box Trough : Material Stainless Steel, Compatible limit. Trough Agitator : Material Stainless Steel, driven by FHP engine with Reduction Gearbox. Slurry Tank : Stainless Steel, limit 75 Ltrs. Slurry Pump : Gear Pump with HP engine Slurry Tank Agitator : Stainless Steel Impeller with SS Shaft coupled to FHP engine and Reduction Gear Box Filtrate Receiver : Material Stainless Steel, Capacity 10 Ltrs. (2 Nos.) Vacuum Pump : Liquid Ring write coupled to a 1 HP Motor Piping : GI and PVC measure Control board Comprises of Standard make On/Off switch, Mains Indicator and so on. Direction Manual : An ENGLISH guideline manual will be furnished alongside the Apparatus A decent quality painted inflexible MS Structure is given to help every one of the parts.

Ribbon Mixer

SML-0074

Strip Mixer A lace blender comprises of a level trough containing a focal shaft and a helical lace fomenter. Two balancing strips are mounted on a similar shaft, one moving the strong gradually one way, the other moving it rapidly in other. The strips might be ceaseless or interfered. Blending comes about because of the turbulence instigated by the checking instigators, not from unimportant movement of solids through the trough. Some lace blender works cluster astute with the solids charged and blended until palatable; others blend consistently, with solids encouraged in one end of the trough and released from the other. Lace Blenders are powerful blenders for thin glues or for powders that don't stream radially. The entire gathering is fitted on unbending MS structure. The trough is emptied through an opening in the base. The setup considers in standards of blending and can be worked as clump savvy or persistently. Experimentation: To contemplate the working of Ribbon blender Utilities Required : Material for Feed. Electric Supply : Single stage, 220 V AC, 1 kW. Floor Area 1 m x 1 m. Specialized Details : Mixing trough : Material Stainless Steel Size 400x200x250mm (approx.) with half circle base Ribbon : Material Stainless Steel, Double helicoids compose. Cover for Trough : Material Stainless Steel Drive : HP engine coupled to Reduction Gear Box. Gathering Bin : 1 No. PVC Control Panel Comprises : Standard make On/Off switch, Mains Indicator and so on. Guideline Manual : An ENGLISH direction manual will be given along the Apparatus A decent quality painted inflexible MS Structure is given to help every one of the parts..

Screw Conveyor (Variable Speed)

SML-0075

Screw Conveyor (Variable Speed) The screw transport is one of the most seasoned and most adaptable transport composes. These are reduced, requiring little headroom and no arrival component. The material is additionally blended as it goes through the transport. Screw or helical flight transports comprises of a steel shaft having a winding or helical balance secured to the pole and turning in a trough without touching the trough, so the helical balance pushes the material along the trough. It is fitted with a variable speed engine. Drive with a perfect lessening gearbox to run the screw transport at variable speed. A RPM marker with Proximity sensor demonstrates the RPM of transport. Experimentation: To think about the impact of different working parameters on passing on. To think about the impact caused by changing the point of slant. To examine the impact of RPM on proficiency of transport. Utilities Required : Material for Feed. Electric Supply : Single stage, 220 V AC, 1 kW. Floor Area 1 m x 2 m. Specialized Details : Trough : Material Stainless Steel Length 750mm. (approx.) Screw : Material Stainless Steel Dia 75mm, Length 750mm., Pitch Scale 75mm Central Shaft for Screw : Material Stainless Steel, Length 750mm. Drive : Standard make FHP Motor with Drive coupled to Reduction Gear Box. Nourish Hopper : Suitable limit with encourage control game plan. Canisters : 2 Nos. Gathering Bin and Distributing Bin Special game plan for changing the edge of slant 0° – 30°. Control board Comprises of: RPM Measurement : Digital RPM Indicator, Non Contact compose with Proximity sensor. Standard make On/Off switch, Mains Indicator and so on. Guideline Manual : An ENGLISH direction manual will be given along the Apparatus A decent quality painted unbending MS Structure is given to help every one of the parts..

Bucket Conveyor

SML-0076

Basin Conveyor Bucket lifts are utilized when the main course of movement is vertical. There could be three kind of pail transports; radial release, positive release, constant release can transport. The present set-up is an outward release basin transport in which pails are reasonably separated on a belt, which is driven with adequate speed to release the can over the head wheel by the radiating power. It might be utilized for any, material that is released unreservedly from the containers. High limit is gotten by huge quantities of pails and not by speed. The hardware is of Lab. Measure with little cans. The drive is given through a diminishment adapt box coupled to an engine. Gathering canister and nourish box is given the gear. It exhibits the working of container transport as utilized as a part of the businesses. Experimentation: To think about the working of a Bucket Conveyor. Utilities Required : Material for Feed. Electric Supply : Single stage, 220 V AC, 1 kW. Floor Area 1 m x 1 m. Specialized Details : Buckets : Material Steel./Plastic Belt : Nylon./Synthetic Drive : HP engine coupled to Reduction Gear Box. Nourish Hopper : Suitable limit with sustain control plan. Containers : 2 Nos. Gathering Bin and Distributing Bin Control Panel Comprises of: Standard make On/Off switch, Mains Indicator and so forth. Direction Manual : An ENGLISH guideline manual will be given along the Apparatus A decent quality painted unbending MS Structure is given to help every one of the parts.

Plate and Frame Filter Press

SML-0077

Plate and Frame Filter Press Pressure channels can apply a vast weight differential over the septum to give monetarily quick filtration with gooey fluids or fine solids. The most widely recognized sorts of weight channels are channel press. A channel press contains an arrangement of plates intended to give a progression of chambers or compartments in which solids may gather. The plates are secured with a channel medium, for example, canvas material. Slurry is admitted to every compartment under strain; alcohol goes through the canvas fabric and out a release pipe, leaving a wet cake of solids behind. Plates and edges sit on a level plane in a metal rack, with material covering the substance of each plate, and are pressed firmly together by a screw. Slurry enters toward one side of the get together of plates and edge. It goes through a channel running the long way through one corner of get together. The set up comprises of 7 plates and 6 outlines. Edges are secured with channel material. Encourage is bolstered by outfit pump at the best and filtrate gathered at the base from each plate by working the cockerel. In the wake of evacuating Cake, washing and cleaning should be possible by water gave by overhead tank. Bay outlet weights are estimated by weight measures. Rate of filtrate evacuations is estimated by aligned tank gave. Experimentation: To think about the task of channel press in the research center. To assess particular cake obstruction and medium opposition. Utilities Required : Electric Supply : Single stage, 220 V AC, 1.5 kW. Water supply. Deplete. Slurry required to performing test. Specialized Details : No. of casing :6 No. of Plates :7 Size : 200 mm x 200 mm. Material : Acrylic Screw Jack plan for fixing and expelling of edges effectively. Channel Medium : Filter Cloth Filtrate gathering plate : Material Stainless Steel, Suitable size. Whirlwind Feed tank : Material Stainless Steel, Capacity 40 Ltrs. Slurry Tank Agitator : Stainless Steel Impeller with SS Shaft coupled to FHP Motor and Reduction Gear Box Slurry Feed Pump : Gear Pump with FHP engine. Channeling framework : GI and PVC. Filtration rate estimation : Using estimating tank. Material Stainless Steel Pressure Measurement : Bourdon compose weight check. Overhead water tank : Material Stainless Steel , Capacity 25 Ltrs. Control board Comprises of Standard make On/Off switch, Mains Indicator and so forth. Direction Manual : An ENGLISH guideline manual will be furnished alongside the Apparatus A decent quality painted inflexible MS Structure is given to help every one of the parts.
