Quick answer. The decision that matters in a theory of machines laboratory is not how many rigs to buy but whether each rig can be measured. Almost every apparatus in TOM-0001 to TOM-0018 rotates or oscillates, and a student only gets a result if speed, torque and amplitude can be read with a stated range and resolution. A rig with no speed readout produces graphs with no axis, and a frame designed without a transducer mounting is very hard to retrofit. So buy fewer rigs, instrument them properly, and ask about data acquisition at the time of ordering.

What this range covers

Eighteen records, coded TOM-0001 to TOM-0018, covering the standard experiment list of a theory of machines or dynamics of machinery course. The rigs: static and dynamic balancing, a motorised gyroscope, a motorised governor, whirling of shaft, cam analysis, a vibration laboratory experiment, generation of an involute gear tooth profile, interference and undercutting, Coriolis component of acceleration, slip and creep measurement, epicyclic gear train holding torque, and a journal bearing apparatus. The instruments: a dead weight pressure gauge tester, tool dynamometers, a contact digital tachometer, a stroboscope tachometer, and a stop watch and stop clock - the last two being accessories rather than apparatus.

The spelling of one record differs from the usual form of the name: the Coriolis component apparatus is listed with an extra letter. It is the standard experiment, and the catalogue text is being corrected.

Speed, Torque, Amplitude

Almost every rig in this listing is a rotating or oscillating machine, and a student can only produce a result from one if three quantities can be measured. This is why the last records in the listing are instruments, and it is the reason a dynamics laboratory so often ends up owning rigs that only demonstrate.

QuantityWhy it decides the experimentWhat to buy with the rig
SpeedNearly every result in this subject is a function of rotational speed - critical speed, governor lift, gyroscopic couple, out-of-balance force. A rig with an uncalibrated motor control and no speed readout produces graphs with no axisA tachometer per rig, contact or non-contact. Both are in this listing
TorqueHolding torque on an epicyclic train, friction torque in a bearing, cutting force on a tool - these are the measured outputs. Ask how torque is read and what its range and resolution areThe tool dynamometer for machining forces; ask what arrangement each rig uses for torque
Amplitude and timeVibration and whirling are amplitude-and-frequency problems. A rig that shows a shaft bowing is a demonstration; one with a dial gauge or a transducer and a timebase produces a measurementAsk whether displacement measurement is included and whether an accelerometer option exists

The honest version of the rule: buy fewer rigs and instrument them properly. Six well-instrumented experiments teach more than twelve that can only be watched, and an uninstrumented rig is very hard to retrofit once the frame has been designed without a mounting for a transducer.

The stroboscope trap, which catches a class every year

A stroboscope tachometer is an excellent instrument - non-contact, nothing to load the shaft, and it shows the shape of the motion as well as the speed - and it has one failure mode that produces confidently wrong numbers. A rotating mark appears frozen not only at the true speed but also at simple submultiples and integer multiples of it: a shaft turning at nine hundred revolutions per minute shows a single stationary mark at four hundred and fifty flashes per minute as well as at nine hundred, and at eighteen hundred it freezes as two marks half a turn apart.

The discipline is simple and should be taught with the instrument: start above the expected speed and work the flash rate downwards, and take as the answer the highest flash rate at which a single stationary image appears. Then confirm it with the contact tachometer on the first run of any new rig. A laboratory that owns both instruments and uses them against each other has a built-in check; one that owns only the stroboscope will eventually publish a result that is half or double the truth.

The rigs that need respect: whirling, balancing and the gyroscope

Whirling of shaft is the one experiment in a mechanical engineering laboratory that deliberately runs a machine at its own critical speed. That is the point: the shaft deflects dramatically as it passes through resonance, which is the phenomenon being taught and also the reason the rig must be treated carefully. Ask what guard encloses the shaft over its whole length - a transparent tube is the usual and the right answer; ask what the maximum permitted speed is and whether the drive is limited to it; ask how the shaft is held and what happens if it is overtightened; and ask whether the frame must be bolted to the bench or floor, because an unanchored whirling rig walks.

The balancing apparatus and the motorised gyroscope both spin masses in the open. Ask about guarding, about how masses are secured - a grub screw is not enough on a disc that will be spun - and about the speed range and the emergency stop. The governor rig raises its weights as speed rises, which means moving parts at head height on a bench; ask the same questions.

One general rule for this listing: any rig with an exposed rotating mass should have a guard, a bolt-down and a stop within reach of the student operating it. Ask for all three in writing. It is reasonable, and it is also what an institutional safety inspection will look for.

The experiments where the conditions decide the answer

The journal bearing apparatus measures the pressure distribution around a loaded bearing, and the result cannot be compared with theory unless the oil is known: viscosity is strongly temperature-dependent, so the oil grade and the oil temperature are part of the result. Ask what oil the rig takes, whether temperature is measured at the bearing, how many pressure tappings there are around and along the bearing, and how load and speed are set and read. Ask also about the drip tray and the oil change arrangement, because a teaching bearing rig leaks.

Cam analysis plots follower displacement against cam angle, so the question is how both are measured: a dial gauge and a graduated disc read by hand, or a transducer and an encoder. Both are legitimate; the first teaches the method and takes a whole session, the second produces a curve in minutes. Ask which cams and followers are supplied, since the set of profiles is what the experiment actually explores.

Involute generation, interference and undercutting are not machines at all - they are kinematic models that draw or demonstrate gear tooth geometry. They are among the most useful items here for a lecture, because the geometry is almost impossible to teach from a static diagram. Ask what is produced - a drawn profile the student keeps, or a demonstration - and whether blanks and drawing media are consumables. Gear and mechanism models proper are listed under engineering training models.

Slip and creep measurement applies to belt drives, and the dead weight pressure gauge tester is a pressure calibration instrument rather than a dynamics rig; a second record for it appears in our hydraulics bench workshop listing, where its calibration questions are set out, including the one refinement worth knowing - that a dead weight tester generates pressure from mass under gravity, so if it is used as a laboratory reference, the gravity value it was calibrated for should be recorded with it.

What to ask for on the quotation

For each rig: the measured quantities and how each is read, with range and resolution; speed range, drive type and how speed is controlled and displayed; guarding, bolt-down requirement and emergency stop; what consumables and spare parts the experiment uses - oil, belts, cams, masses, drawing media; bench or floor mounting, mass and footprint; the experiment list and worksheets supplied, to compare against your syllabus; and whether a data acquisition option exists, since that is hard to add later. For the instruments: measuring range, accuracy, calibration certificate and traceability. For everything: services at the position, nominal voltage, frequency and plug pattern, and the warranty and local service position. For any certification stated here, contact us for the latest copies of the relevant certificates before you tender on it.

Related ranges: engineering training models for gears, cams, linkages and mechanisms as teaching models, machines for thermodynamics, structures and tribology apparatus, cutaways models for sectioned machinery, the test and measurement workshop range for instruments, and universal testing machines for materials testing. The full set is listed under engineering apparatus. For a quotation, tell us the destination country, your syllabus experiment list, the class size in one practical session and whether you need data acquisition on any rig.

Frequently asked questions

What instruments should we buy alongside the theory of machines rigs?

Plan for the three quantities the experiments depend on. Speed: nearly every result - critical speed, governor lift, gyroscopic couple, out-of-balance force - is a function of rotational speed, so budget a tachometer per rig; contact and stroboscope types are both in this listing. Torque: holding torque on the epicyclic train, friction torque in the bearing and cutting force on a tool are the measured outputs, so ask how each rig reads torque, with range and resolution. Amplitude and time: ask whether displacement measurement is included and whether an accelerometer option exists for the vibration and whirling rigs.

How do students avoid wrong speed readings with a stroboscope tachometer?

A rotating mark appears stationary not only at the true speed but also at integer multiples and simple submultiples of it, so a shaft turning at nine hundred revolutions per minute will also stand still at four hundred and fifty flashes per minute. Teach the discipline with the instrument: start above the expected speed, work the flash rate downwards, and take the highest flash rate at which a single stationary image appears. Then confirm it with the contact tachometer on the first run of any new rig. A laboratory that owns only the stroboscope will eventually report half or double the truth.

What safety features should the whirling of shaft apparatus have?

Whirling of shaft deliberately runs a shaft through its own critical speed, so the dramatic deflection being taught is also the hazard. Ask what guard encloses the shaft over its whole length - a transparent tube is the usual and the right answer. Ask the maximum permitted speed and whether the drive is limited to it, how the shaft is held and what happens if it is overtightened, and whether the frame must be bolted to the bench or floor, because an unanchored whirling rig walks. Ask for the guard, bolt-down and stop arrangement in writing.

Are the balancing apparatus, gyroscope and governor safe to run in an open teaching lab?

They can be, if the right questions are asked. The static and dynamic balancing apparatus and the motorised gyroscope both spin masses in the open, and the governor raises its weights as speed rises, putting moving parts at head height on a bench. Ask about guarding, how masses are secured - a grub screw is not enough on a disc that will be spun - the speed range and the emergency stop. The page's general rule applies: any rig with an exposed rotating mass should have a guard, a bolt-down and a stop within reach of the operating student.

Why do journal bearing results not match theory?

Usually because the oil is not known. The journal bearing apparatus measures pressure distribution around a loaded bearing, and oil viscosity is strongly temperature-dependent, so the oil grade and the oil temperature are part of the result. Ask what oil the rig takes, whether temperature is measured at the bearing, how many pressure tappings there are around and along the bearing, and how load and speed are set and read. Ask also about the drip tray and the oil change arrangement, because a teaching bearing rig leaks, and keep the specified oil as a consumable.

Should the cam analysis apparatus use a dial gauge or a transducer?

Both are legitimate; they teach different things. Cam analysis plots follower displacement against cam angle, so the question is how both are measured. A dial gauge and a graduated disc read by hand teach the method and take a whole session; a transducer and an encoder produce the curve in minutes. Decide which your course needs, then ask which cams and followers are supplied, since the set of profiles is what the experiment actually explores. The involute generation and interference and undercutting items are different again: kinematic models for lectures, so ask whether blanks and drawing media are consumables.

Key takeaways

  • Instrument before you multiply: fewer rigs that can be measured teach more than many that can only be watched.
  • Speed, torque, amplitude: ask how each rig reads all three, with range and resolution, before comparing anything else.
  • Strobe from the top down: take the highest flash rate giving a single stationary image, then check it with the contact tachometer.
  • Guard, bolt-down and stop, in writing: every rig with an exposed rotating mass needs all three within reach of the student.
  • The oil is part of the bearing result: grade and temperature at the bearing must be known for the journal bearing data to mean anything.
  • Ask for data acquisition now: it is hard to add later, and an uninstrumented frame is difficult to retrofit.

About this page

Ray Export is a manufacturer and exporter of laboratory, scientific and educational equipment based at Plot No. 449, HSIIDC Industrial Area, Saha, Ambala, Haryana 133104, India. Enquiries: [email protected], +91-9817319615.

Written by Palak Mall, Senior Content Writer. Technically reviewed by Arvind Kumar, Lab Equipment Specialist, 12+ years in laboratory and testing instrumentation. Last updated: 17 October 2026.

Specifications for each rig and instrument - measured quantities, range and resolution, speed range, guarding, mounting, mass and footprint - are confirmed in writing on the quotation. For calibration certificates, standards or approvals, contact us for the latest copies of the relevant certificates. No price is quoted on this page. Listing note: the Coriolis component apparatus is spelt with an extra letter in its record; the stop watch and stop clock are accessories counted among the eighteen records; and the dead weight pressure gauge tester is a pressure calibration instrument with a second record in the hydraulics bench workshop listing.
