Quick answer. A universal programmer is worth exactly as much as its device library, so choose against the parts your laboratory actually uses. Send that list and ask for written confirmation that each part is supported, rather than accepting a device count, and ask how library updates are delivered and for how long they are free. Then settle the computer requirement - operating system, software licence, seats and drivers - which is the most common reason a programmer arrives unusable. EPP-0001, EPP-0002 and EPP-0003 carry effectively the same name, so quote the code and ask for a specification against each.
Four items are listed here: EPP-0001 and EPP-0003, both named Universal Programmer Tester, EPP-0002 Universal Programmer Tester PR-02, and EPP-0004 EPROM Eraser. Two things to settle at the outset. The three programmers carry effectively the same name, so quote the code and ask for a specification against each. And the eraser is the one item on this page with a real hazard attached: it works by short-wave ultraviolet light, which injures eyes and skin without any sensation at the time, so read that section before ordering it.
| Code | Item | What to establish |
|---|---|---|
| EPP-0001 | Universal programmer tester | Device library, socket, computer requirement |
| EPP-0003 | Universal programmer tester | Carries the same name as EPP-0001; ask what differs |
| EPP-0002 | Universal programmer tester, model PR-02 | As above, and which of the three is current |
| EPP-0004 | EPROM eraser | Lamp type, lid interlock, erase time, lamp life |
A universal programmer reads, programmes and verifies memories and programmable logic from a library of supported devices, and it is worth exactly as much as that library is current. Ask, against each code:
One note on the technology. Ultraviolet-erasable read-only memory has largely been displaced by electrically erasable memory and flash, which are programmed and erased in circuit and need no eraser at all. If your syllabus specifically teaches ultraviolet-erasable devices, the apparatus here suits it, but ask whether the devices themselves are still obtainable in the quantities a class needs, and consider whether the practical would be better taught on a flash part.
An eraser of this kind contains a short-wave ultraviolet lamp. Short-wave ultraviolet is invisible and produces no warmth and no discomfort while it is being absorbed, so there is no warning sensation. Over-exposure of the eyes causes a painful inflammation of the cornea that appears hours later, and skin exposure causes burning in the same way sunlight does but faster. None of this is a reason not to own one; it is a reason to insist on the following and to say so in the laboratory rules:
Programming work means loose integrated circuits, which is where static damage happens. Set the bench up with a wrist strap and a dissipative mat and store devices in conductive foam or tubes. Never insert or remove a device with the socket powered, check pin one orientation before closing the socket, and do not force a part with bent leads, since that damages the socket rather than the part. Ask what a replacement socket costs and whether it can be changed by a technician, because on a programmer the socket wears out first.
Besides the three similarly named programmers here, a universal programmer also appears in the Testing and Measuring Lab Trainers listing under its own code, and integrated circuit testers are listed both there and under IC Tester and Digital IC Tester. Ask the supplier to put the overlapping codes side by side and quote once for the unit you need.
The manual and the supported device list as a document, not a figure; the quantity needed, which for a programmer and an eraser is usually one or two per laboratory rather than one per bench; the supply voltage, frequency and plug type for your country; spare sockets, adapters and lamps with prices; and the warranty. Any device count or coverage claim is confirmed in writing on the quotation; ask for the list.
Functional testing of logic and linear devices is under IC Tester and Digital IC Tester. The boards these devices are programmed for are under Microprocessor Trainers and Kits, Embedded System Trainers and VLSI Design Training Systems. Components are under Electronic Components, digital foundations under Digital and Analog Trainers and Kits, and instruments under Testing and Measuring Lab Trainers. Parent range: Electronics Lab Trainer Kits.
Send your device list and ask for written confirmation that each part is supported, plus the software and licence position. For example Universal Programmer (EPP-0002) and EPROM Eraser (EPP-0004), one of each, with the device list, the update policy and the eraser's lid interlock confirmed in writing. Contact Ray Export for prices, device lists and lead times.
The listing does not say. EPP-0001 and EPP-0003 are both named Universal Programmer Tester, and EPP-0002 adds only the model suffix PR-02. Quote the code you want, ask for a specification against each of the three - device library, socket, computer requirement - and ask which is the current model. A further universal programmer appears in the Testing and Measuring Lab Trainers listing under its own code, so ask the supplier to put the overlapping codes side by side and to quote once for the unit you actually need.
Ask, because that is how current microcontrollers are normally loaded. In-system programming means programming a device already soldered into a board through a programming header; confirm whether the unit supports it and whether the cable and adapter are included. For socket programming, ask the pin count of the zero-insertion-force socket and which adapters exist for surface-mount packages, since most programmers take dual-in-line parts only. Note that ball-grid-array devices cannot normally be socket-programmed at all, so in-system programming is the only route for them.
Ask whether the unit works standalone or needs a computer; if it does, ask which operating system and version, whether the software and licence are included, how many seats, and whether the drivers work on your machines. This is the most common reason a programmer arrives unusable. Then confirm the functions beyond programming: blank check, read back, verify after write, device identification, and whether it can set security or lock bits, which is irreversible on many devices and worth knowing before a student does it. If your course uses older parts, ask what programming voltages the unit supplies.
Only if your syllabus specifically teaches ultraviolet-erasable devices. Ultraviolet-erasable read-only memory has largely been displaced by electrically erasable memory and flash, which are programmed and erased in circuit and need no eraser at all. If the course does teach ultraviolet-erasable parts, the EPP-0004 eraser suits it, but ask whether the devices themselves are still obtainable in the quantities a class needs, and consider whether the practical would be better taught on a flash part. For a programmer and an eraser, one or two per laboratory is usually enough.
It is safe only with the right controls. EPP-0004 contains a short-wave ultraviolet lamp, which is invisible and gives no warmth or discomfort while it is being absorbed. Over-exposure of the eyes causes a painful inflammation of the cornea that appears hours later, and skin burns as in sunlight, but faster. Insist on a lid or drawer interlock that cuts the lamp when the enclosure is opened, check it on arrival and periodically, and never defeat or bypass it. Nobody looks at the lamp or reaches inside while it runs, and the unit belongs in a ventilated place, since the lamp can generate irritant ozone.
Erase time depends on the devices and on the lamp's condition, so ask whether the unit has a timer and what erase time is recommended for the devices you use. Guessing costs you either way: too little and the device is only partly erased and behaves unpredictably; too much and repeated over-erasure degrades it. Lamp output falls with use long before the lamp fails, so erase times lengthen over time. Ask the rated lamp life, whether a replacement lamp is available, and how the lamp is changed, which should only be done with the unit unplugged.
Ray Export is a manufacturer and exporter of laboratory, scientific and educational equipment based at Plot No. 449, HSIIDC Industrial Area, Saha, Ambala, Haryana 133104, India. Enquiries: [email protected], +91-9817319615.
Written by Palak Mall, Senior Content Writer. Technically reviewed by Arvind Kumar, Lab Equipment Specialist, 12+ years in laboratory and testing instrumentation. Last updated: 17 October 2026.
Every specification, including the device library, the software licence and the eraser's lamp details, is confirmed in writing on the quotation; ask for the supported device list as a document rather than a figure. For certificates, contact us for the latest copies of the relevant certificates. No price is quoted here. Listing defects noticed: EPP-0001 and EPP-0003 carry the same name and EPP-0002 differs only by a model suffix, with no stated difference between the three; and a further universal programmer appears in the Testing and Measuring Lab Trainers listing under its own code.
Device supports more than 4000+ devices, 40 Pin ZIF socket with universal pin-drivers to supports 8-pin to 40-pin DIP package device, USB Interface to LAPTOP & PC and High speed programming, Cost effective Hardware and Flexible Software.
Device supports more than 7000+ devices. Our Testers are offered with 48 Pin ZIF socket with universal pin-drivers to supports 8-pin to 40-pin DIP package device, USB Interface to LAPTOP & PC, High speed programming, Cost effective Hardware and Flexible Software, Top-3000-Universal Programmer-Tester and the Device supports more than 15000+ devices. - 48 Pin ZIF socket with universal pin-drivers to supports 8-pin to 40-pin DIP package device - USB Interface to Laptop & PC - High speed programming, Cost effective Hardware and Flexible Software.
Universal Programmer Tester - Device supports more than 15000+ devices, 48 Pin ZIF socket with universal pin-drivers. to supports 8-pin to 40-pin DIP package device - USB Interface to LAPTOP & PC. - High speed programming, Cost effective Hardware and Flexible Software
Eprom Eraser - Auto shut OFF after predetermined time, selectable by the Timer. Built in spring loaded mechanical timer with auto rewinding for setting time 0-30/60 minutes. 6\"/9\" Ultra Violet Tube. 8 to 10 EPROMs can be erased at a time.
